Single package X-ray inspection
- Model
- SD-X-3500L,SD-X-3500D,SD-X-4000
Item specifics
- Food x ray inspection equipment software
- Intellisense® Softwore
- x ray inspection system
- Windows XP
- Power supply
- 100~240VAC, 50/60Hz
- automatic x ray inspection detector type
- linear scan
- x ray food inspection systems display
- 15''LCD
Review
Description
Single package X-ray inspection, you can：
●MTBF, MTTR analysis and equipment management.
●x ray food inspection systems have report printing function.
●Reminder function.
Single package X-ray inspection advantages：
Single package X-ray inspection is SYNDAR's new online metal detector x ray machine. Wherever X-rays go,It can detect the missing packaging box and empty packaging of sealed products. If the packaging does not meet the requirements, errors will be recorded to ensure that the products leave the factory without defects.
●Provide production records and life management records of main parts.
●x ray inspection for food industry provides in-depth optimization services for product characteristics.
●The equipment can be cleaned with water.
●The food x ray machine price provided by SYNDAR has great advantages in the market.
|
Model
|
SD-X-3500L
|
SD-X-3500D
|
SD-X-4000
|
|
Conveying bandwidth (mm)
|
410
|
410
|
600
|
|
Conveyor height (mm)
|
850±30
|
850±30
|
850±30
|
|
Conveyor speed (m/min)
|
10~100
|
10~100
|
10~60
|
X-Ray output | 80kVp/1.25mA | 80kVp/7mA | 80kVp/1.25mA |
X-Ray leaked | ＜1uSv/h | ＜1uSv/h | ＜1uSv/h |
Detector type | Linear scan | Linear scan | Linear scan |
Pixel size | 0.4mm | 0.4mm | 0.4mm |
Display | 15'' touch screen | 15'' touch screen | 15'' touch screen |
Software | Intellisense® Softwore | Intellisense® Softwore | Intellisense® Softwore |
operating system | Windows XP | Windows XP | Windows XP |
power supply | 100~240VAC，50/60Hz | 100~240VAC，50/60Hz | 100~240VAC，50/60Hz |
Operating environment | Ambient temperature: 50~35°/humidity: 30~85%RH (no condensation) | Ambient temperature: 50~35°/humidity: 30~85%RH (no condensation) | Ambient temperature: 50~35°/humidity: 30~85%RH (no condensation) |
Weight (Kg) | 350 | 350 | 580 |
Size (mm) | 900×920×1825 | 900×920×1825 | 1800×1030×1900 |
Product size chart
Features of Glass X-ray inspection:
Image selection and magnification: 1-9 selections can be selected and zoomed in 2/4/8 to achieve full-screen observation.
In order to avoid the risk of being retrieved due to food safety issues, SYNDAR x ray inspection systems manufacturers provide corresponding x ray machine food safety solutions.
The x ray inspection system for food can perform excellent physical contamination detection on high-density contaminants such as high-density plastics.
Applications：
Even products with high humidity, high salt content, or metal outer packaging can still be tested.
It can detect whether there are foreign objects in the packaged snacks, and it can also detect whether the packaging is defective.
You can choose this detector to detect foreign objects in daily necessities packaging bags, such as bottled laundry products.
It can detect whether there are other impurities in the packaged toy, and it can also find out whether the product is missing in time while testing.
